JDSU 100G PM-QPSK QPMZ Optical Modulator Single Ended Each 32 Gbaud 2202/2201/2200

The Lumentum 100G PM-QPSK modulator is designed according to the widely

accepted OIF 100GE Tx implementation agreement.

It supports the dual polarization-QPSK modulation scheme, with each of four

parallel MZI’s running at speeds of up to 32 Gbaud.

The chip design features low insertion loss (with very small polarization dependent loss)

as well as a high bandwidth with quasi-linear electro-optic roll-off.

Features

100 Gbps generated from four 25 Gbaud signals (polarization multiplexed 2*50G QPSK, plus FEC)

Single ended

Low insertion loss

Fully integrated with polarization combiner

Designed to OIF implementation agreement

Leading transmission performance

Low drive voltage

Low skew

Applications

100G metro to ultra-long haul transmission with highest spectral efficiency

DWDM over 10G infrastructure (with coherent detection)

100G transponders and linecards

Other modulation formats

Compliance

Qualified to GR-468
